#057 - 29+ Trail Hardtail

This might be the first steel frame with a dropper post of the Austria based company “Eightpins”. These posts have very special technical requirements to the frame, but the performance of the dropper is absolutely worth the effort.

Projekt: 29+ Trail MTB

Rohrsatz / Tube Set: Columbus Zona

Ausfallenden / Drop Out: Paragon UDH / 148mm x 12mm

Schaltauge / Hanger: UDH

Tretlagerhülse / Bottom Bracket Shell: T47 / 92mm

Antrieb / Drivetrain: 1x12

Steuersatz / Headset: Ø 46mm for S.H.I.S. ZS44 / ZS44

Sattelstützklemmung / Seat Post Clamp: custom “Eightpins” Seat tube

Bremsen / Brakes: Disc Post mount 160mm

Zugführung / Cabel Routing: Internal Routing

Reifenfreiheit / Tire Clearance: 29 x 3.0”

Gabel / Fork: Rock Shox Pike 140mm

Schutzblech / Fender Mount: no

Flaschenhalter / Bottle Cage: 1 x Down Tube

Electric Cable: no
